SHADOW 112HC/EN is a medium-output, weather-resistant 2-way coaxial loudspeaker designed for professional indoor and outdoor installations. Fully UV-protected and rated IP55, it is suitable for applications such as stadiums, sports facilities, theme parks, swimming pools, cruise ships, and outdoor background music systems.
The system features a 12″ woofer with 2.5″ voice coil and a 1″ high-frequency compression driver with 1.7″ voice coil in a coaxial configuration. The enclosure is a single-piece rotomolded polyethylene cabinet, fully UV-resistant, equipped with a custom perforated stainless-steel grille with three protective layers and a stainless-steel U-bracket for secure installation.
With a frequency response from 98 Hz to 19 kHz, the SHADOW 112HC/EN delivers high intelligibility and reliable performance in harsh environmental conditions.
The SHADOW 112HCT/EN includes an integrated 100 V line transformer with selectable 200 W and 100 W power taps, selectable via 4-wire cable.
-
Configuration: 2-way
-
Low Frequency Woofer: 12″ / 2.5″ VC
-
High Frequency Driver: 1″ / 1.7″ VC
-
Transformer (optional): 100V – taps: 200 / 100 W
-
Recommended Amplifier: 400W RMS
-
Maximum SPL: 123 dB
-
Material: UV-resistant molded polyethylene with 3-layer stainless steel grille
Technical Specifications
41810 (HCT/EN) - 41924 (HC/EN)
2 way
400W
200W
800W
8 ohm
98Hz - 19KHz -6dB
2'' - 2.5'' VC
1'' - 1.7'' VC
101 dB
123 / 111 dB (1mt/4mt)
100° x 100° (500Hz)
1.6 KHz
80hz - 24dboct
---
4 wire cable
430 x 430 x 419 mm / 16.9 x 16.92 x 16.4 inch
23.4 Kg / 51.5 lb
