FBT PROMISES INFINITO CONTROL OF NETWORKED AUDIO

ITALY’S AUDIO SPECIALIST UNVEILS A PROPRIETARY SYSTEM MANAGEMENT SOFTWARE SUITE


FBT is redefining the remote monitoring and control of professional sound reinforcement systems with the release of the INFINITO system management suite. Entirely developed in-house by FBT’s Research and Development team, INFINITO delivers seamless operation of and new ease of use for all FBT active loudspeakers, matrix processors, and processing power amplifiers.

Infinito_Logo block

A real revolution in FBT world that enhances the user experience to a new level of performance and simplicity!

Leveraging the stability of industry-standard windows 7, 8 and 10 operating systems, Infinito utilises a TCP/IP protocol based on the proven AES70 Open Control Architecture (OCA) standard, and operates over the universally adopted Ethernet infrastructure for professional audio networking. More than 100 DSP devices can be connected on the same TPC/IP network with the added convenience of automatic IP address assignemt. In addition, INFINITO offers accurate control and monitor of health and status of any connected devices in real time giving the user instant feedback via the touch-orientated graphical interface. The multi-level device control detail give the option to concentrate on an overview of the entire system or to focus on the parameters of a single device.

Infinito also offers a wealth of labour-saving functions wich are geared towards enabling best practice audio system design with the minimun of setup and configuration. Users can save time by designing a project off-line and in advance of an event by calling from FBT’s comprehensive library of DSP-based devices; INFINITO’s innovative GUI allows access to the three operation modes of SETUP, TUNING, and SHOW – each of these modes are security password protected to avoid accidental or unintentional changing of parameters.

Infinito_info_block

SYSTEM TECHNICIANS WILL SIMILARLY APPRECIATE THE ABILITY TO CUSTOMISE THE INTERFACE’S MULTI-LEVEL DEVICE CONTROL DETAIL, GIVING THE OPTION TO CONCENTRATE ON AN OVERVIEW OF THE ENTIRE SYSTEM IN A SINGLE WORKSPACE, OR TO FOCUS SOLELY ON THE PARAMETERS OF A SINGLE DEVICE.

Powerful grouping features allow users to create groups of virtual networked devices and control them independently on two different levels. Basic or advanced, making assignmet and control easy for the operator, in addition, Group Contribution Overview enables the effect of group settings on device parameters to be quickly checked and modified.

Further flexibility is delivered courtesy of Infinito’s features: Day and Night skins ensuring high visibility even in bright sunlight conditions, multiple scene snapshot and recall, custom summary table style panel with immediate visual feedback, and LIVE function to send settings to all devices in real time.

Infinito_SlideGallery

Infinito also offers a wealth of labour-saving functions wich are geared towards enabling best practice audio system design with the minimun of setup and configuration

Users can save time by designing a project off-line and in advance of an event by calling from FBT’s comprehensive library devices; INFINITO’s innovative GUI allows access to the three operation modes of SETUP, TUNING, and SHOW – each of these modes are security password protected to avoid accidental or unintentional changing of parameters.

Infinito_features_list

  • Compatible with Windows 7, 8, and Windows 10
  • TCP/IP protocol based on AES70 (OCA Alliance) standard
  • Ability to communicate with 3rd party devices and OCA compliant software
  • Enterely based on standard Ethernet infrastructure, requires only Ethernet cable
  • Connect more than 100 devices on the same TCP/IP network with DHCP or AUTO IP address assignment
  • Daisy Chain between devices with hardware bypass function
  • Accurate real time control of  all connected device’s parameters
  • Monitor the healt and status of any connected device in real time
  • Intuitive fast-acting touch oriented graphical user interface
  • Create custom summary panels with immediate visual fedback, control specific parameter in table style format
  • Advanced and Basic groups management: group is treaded as a virtual device to semplify assignment and operation

  • Night and Day skin to adapt to ambient light conditions
  • GROUP CONTRIBUTION OVERVIEW table: user can check the contribution of each group settings to device parameters
  • Multiple Scene snapshot creation and recall
  • Extensive logging features
  • Automatic device firmware update
  • SETUP, TUNING and SHOW operating modes with security password to switch one to other, authorization settings to change parameters
  • OFFLINE and ONLINE operation mode: offline projects reduces soundcheck time
  • Extensive security management with lock screen and lock device functions
  • Live function: send settings to all devices or a single device in real time
  • Global Mute
  • Multi-level device control detail: monitor settings the entire system in a single overview, or focus on details of a single device
